Shopify - Product mapping – Boyum Help Center

The table below lists all the possible mappings supported via the Shopify Connector. For a more detailed description for each field see the Shopify GraphQL API documentation.

Mapping to field	Output Kind	Description
SyncID (Required)	Field	The SyncID will be updated with Shopify Id for the product. NOTE: if more than one channel is used, then this parameter must be independent for each channel.
SyncDate (Required)	Field	The SyncDate will be updated with Shopify “Updated At” for the product. NOTE: deleting SyncDate value for chosen product will lead to product update in Shopify on next synchronization. NOTE: if more than one channel is used, then this parameter must be independent for each channel.
Key (Required)	KeyField	A KeyField mapping is required. Usually “Value“ or “@Id” depending on value used in “ECommerceVariantOfProduct”
Title (Required)	Field	The title of the product. The Title is translatable.
SyncMsg	Field	SyncMsg will be used for reporting errors back to products in Perfion.
Collections	RelatedCategory	This is a special parameter, which allows to specify the link from Perfion product to Perfion category, which will be converted to the link from Shopify product to Shopify custom collection by using Shopify collects. To link multi collections, use a Multi feature.
Options	VariantDimension	The value is a comma separated list of feature names (unique feature name should be used), which define product variant options. The Options is translatable.
BodyHtml	Field	A productdescription in plain test or Html. The BodyHtml is translatable.
Category	Field	The Id of the node in the Shopify product taxonomy that represents the product category. E.g. “el-1-1” for “Basketball Arcade Games → Arcade Equipment → Electronics”. Find the Id in Shopify Taxonomy Explorer (From version 2.1.0.).
CustomProductType	Field	The custom product type specified by the merchant. Deprecated from version 2.1.0. Use the ProductType field instead
GiftCard	Field	A boolean true/false to determine whether the product is a gift card.
GiftCardTemplateSuffix	Field	The theme template used when viewing the gift card in a store.
Handle	Field	A unique, human-friendly string for the product. Automatically generated from the product's title unless otherwise specified. The Handle is translatable.
Image	Image(Url)	An image stored in Perfion (Required the Perfion API is publicly available). The Image will be the thumbnail image (If an Image with output kind Field is mapped, the Field mapping will be the thumbnail).
Images	Image(Url)	Images stored in Perfion (Required the Perfion API is publicly available).
Images(<ImageFeature>)@AltText	Attribute	For Images via Image(Url) it is possible to include an attribute “AltTest” for adding an Alternative text to the image. See Outputting Multi Value-attributes for more information's about attributes on multi values.
Image	Field	An image url. Must be a fully qualified URL path, including protocol. The Image will be the thumbnail image.
Images	Field	Image url's. Must be a fully qualified URL path, including protocol.
Markets	Field	A Multi feature or a comma separated list of Market names the product should be published at.
OnlineStorePublishDate	Field	A date and time in the future if the Category should be publish at a specific time. Shopify only support the publish date for the Online Store. The format can be in: UTC “dd/MM/yyyy HH:mm:ssZ“ with time zone-offset “dd/MM/yyyy HH:mm:ss +HH:mm“ without time zone-offset “dd/MM/yyyy HH:mm:ss” and then the time zone-offset will be taken from the setting ShopifyTimeZone.
ProductCategory	Field	The ID of the node in the Shopify taxonomy that represents the product category. E.g. “gid://shopify/TaxonomyCategory/ap”. Deprecated from version 2.1.0. Use the category field instead.
ProductType	Field	The product type specified by the merchant. The ProductType is translatable.
RedirectNewHandle	Field	A boolean true/false to determine wehether a redirect is required after a new handle has been provided. If true, then the old handle is redirected to the new one automatically.
Requiressellingplan	Field	A boolean true/false to determine whether the product can only be purchased with a selling plan (subscription). Products that are sold exclusively on subscription can only be created on online stores. If set to true on an already existing product, then the product will be marked unavailable on channels that don't support subscriptions.
SalesChannels	Field	A Multi feature or a comma separated list of Sales Channel names the product should be published at.
SeoDescription	Field	SEO description of the product. The SeoDescription is translatable.
SeoTitle	Field	SEO title of the product. The SeoTitle is translatable.
StandardizedProductType	Field	The ID of the node in the Shopify taxonomy that represents the product type. Deprecated from version 2.1.0. Use the category field instead.
Status	Field	The status of the product. Allowed values: Active (Default) Archived Draft Unlisted
Tags	Field	A Multi feature or a comma separated list of tags that have been added to the product.
TemplateSuffix	Field	The theme template used when viewing the product in a store.
Vendor	Field	The name of the product's vendor.
Metafield\|<namespace>\|<key>\|<type>	Field	See Shopify - Metafield Mapping for more information.

Extra mapping for products without variants

Mapping to field	Output Kind	Description
Barcode	Field	The value of the barcode associated with the product.
CompareAtPrice	Field	The compare-at price of the product.
CountryCodeOfOrigin	Field	The country code of where the item originated from.
InventoryPolicy	Field	Whether customers are allowed to place an order for the product when it's out of stock. Allowed values: Continue Deny
Cost	Field	Unit cost associated with the inventory item, the currency is the shop's default currency.
Price	Field	The price of the product.
Price_<MarketName>	Field	The price of the product on a specific market. Currently, it is only possible to set the price in the default Catalog for the Market, as Shopify only supports the default Catalog at this time. Remark: Market names are case-sensitive.
HarmonizedSystemCode	Field	The harmonized system code of the inventory item.
RequiresComponents	Field	A boolean true/false to determine whether the product requires components. The default value is false. If true, then the product can only be purchased as a parent bundle with components and it will be omitted from channels that don't support bundles.
RequiresShipping	Field	A boolean true/false to determine whether the product requires shipping
Sku	Field	The SKU for the product. Case-sensitive string.
TaxCode	Field	The tax code associated with the product.
Taxable	Field	A boolean true/false to determine whether the product is taxable.
Tracked	Field	A boolean true/false to determine whether the inventory quantities is tracked.
Weight	Field	The weight of the product.
WeightUnit	Field	The weight unit of the product. Allowed values: Grams Kilograms Ounces Pounds
Quantity_RefLoc_<location1>	Field	The inventory quantity at the location where the product is stocked. The Inventory quantity can only be set upon product creation as an initial value and cannot be maintained via Perfion afterwards. Set the <location1> in Settings mapping via RefLoc_<location1>.
